Power Distribution
-
Space saving slim form factor
-
IEC power outlet
-
Separates power for the units own power and its power outlets – user interface is still accessible even when an overload condition trips the device’s circuit breaker
-
-
Remote power control via TCP/IP and a built in 10/100 Ethernet port
-
Network Interfaces: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3, auto sense, Ping, Telnet, Modbus (Over TCP IP)
-
Works with web-based software
-
Operation
-
Local and remote power outlet control (On, Off, Power Cycle) by individual outlets
-
Power-on sequencing – users can set the power on sequence and delay time for each port to allow equipment to be turned on in a proper order
-
Easy setup and operation via a browser-based user interface
-
Security
-
Two-level password security
-
Strong security features include password protection and advanced encryption technologies – TLS1.2
-
Remote authentication support: RADIUS
|
Electrical |
|
Nominal Input Voltage |
100 – 240 VAC |
|
Maximum Input Current |
10A Max |
|
Input Frequency |
50-60 Hz |
|
Input Connection |
IEC C14 |
|
Input Power |
2400VA(Max) |
|
Outlet Type |
(4) IEC 320 C13 |
|
Nominal Output Voltage |
100 – 240 VAC |
|
Maximum Output Current (Outlet) |
10A(Max) |
|
Maximum Output Current (Bank) |
10A(Max) |
|
Maximum Output Current (Total) |
10A(Max) |
|
Breakers |
Yes(UL1077) |
|
Metering |
No |
|
Outlet Switching |
Yes |
|
Power Consumption |
AC110V:3.1W:20BTU
AC220V:3.5W:22BTU |
|
Physical Properties |
|
Dimensions(W x D x H) |
44*115*200mm |
|
Weight |
0.90 kg ( 1.98 lb ) |
|
Power Cord Length |
3m |
|
Environmental |
|
Temperature (Operating / Storage) |
0 – 50? / -20 – 60? |
|
Humidity (Operating & Storage) |
0 – 80% RH, Non-Condensing |
|
Compliance |
|
EMC Verification |
CE-EMC |
|
Safety Verification |
CE-LVD |
